SWT 10.50mm
Price range: ₹450.00 through ₹900.00 Inclusive of tax
The RE SWT 10.50 mm Barrier Terminal Block is a heavy-duty, high-amperage PCB mount connector designed for robust power wiring and inverter applications. Featuring an extra-wide 10.50 mm pitch, heavy-duty screw terminals with notched clamping washers, and a high-grade flame-retardant body, it delivers superior electrical clearance, vibration-resistant cable retention, and safe high-current power distribution.
Description
Ensure dependable, heavy-duty power delivery with the RE SWT 10.50 mm PCB Barrier Terminal Block. Specifically engineered for high-current and high-voltage power electronics, the wide 10.50 mm pitch provides high creepage and clearance distances, preventing voltage breakdown and flashovers between adjacent power poles.
Equipped with heavy-duty screw clamps and notched washers, the RE SWT provides firm mechanical holding torque, ensuring wires with ring/fork lugs or bare stranded cables remain tightly locked under continuous vibration. Built with high-conductivity tinned brass contacts and an industrial-grade UL94V-0 rated insulating body, it offers minimal contact resistance, outstanding thermal stability, and long-term durability in demanding power conversion setups.
Key Features
-
Extra-Wide 10.50 mm Pitch: Provides enhanced dielectric insulation and spacious terminal separation for high-voltage power paths.
-
Notched Washer Screw Clamping: Delivers maximum clamping pressure and prevents wire slippage in high-vibration environments.
-
High Current & Voltage Capacity: Built to handle heavy continuous power loads up to 30 A / 300 V–600 V safely.
-
Flame-Retardant Industrial Housing: Molded from premium UL94V-0 thermoplastic for exceptional arc, heat, and flame resistance.
Technical Specifications
| Parameter | Specification |
| Model | RE SWT |
| Pitch Spacing | 10.50 mm |
| Connector Type | Barrier Terminal Block (PCB Mount) |
| Termination Method | Screw with Notched Washer / PCB Solder Pin |
| Housing Material | Thermoplastic / Polyamide (Flame-Retardant, UL94V-0) |
| Contact Material | Solid Brass / Copper Alloy (Tin-Plated) |
| Screw Material | M3.5 / M4 Steel (Zinc-Plated with Notched Washer) |
| Rated Voltage | 300 V – 600 V |
| Rated Current | 25 A – 30 A |
| Applicable Wire Gauge | 22 – 10 AWG (Accepts Lug & Bare Wire) |
| Operating Temperature | -40°C to +105°C |
Additional information
| Pack Size |
50 Pcs ,100 Pcs |
|---|
